VIKING 54 CONVERTIBLE

CONSTRUCTION

• Ablative/Copolymer antifouling bottom paint, 2 coats, primed
• Awlgrip brass thru hulls in engine room and forward bilge
• Awlgrip engine room, lazarette, forward bilge and anchor locker for enhanced visibility and easier maintenance
• Blister resistant modified epoxy resin in entire hull skin
• Bomar hatch, foredeck with Ocean Air screen shade system
• Custom blended polyester resin used in structural laminates, topsides, bridges, and hardtops
• DuPont high gloss polyurethane boot stripe
• Fiberglass side thru hulls
• High gloss, wood interior finish throughout
• High performance isophthalic gelcoat npg superior gloss, flexibility and outstanding weathering characteristics
• Hull infused using Baltek end grain balsa core and Aramid and E-glass hybrid fiberglass laminates
• Infused fiberglass fuel, freshwater and holding tanks with fiberglass baffles inside and balsa coring on side, sealed to hull with resin foam
• Moulded fiberglass salon floor/engine room ceiling with Airex core for acoustical and thermal insulation
• Non Skid moulded in for traction and durability
• Propeller pockets to reduce draft
• Stringers, fiberglass encapsulated foam
• Vacuum bagged composite bulkheads – main engine room bulkheads, and forward bulkhead

MECHANICAL

• Air conditioning — direct expansion, zoned with reverse cycle heat for complete climate control throughout the interior and with individual temperature controls for staterooms and salon
• Bilge pumps with additional clean out pumps on centerline linked into monitoring system and connected to float switches for automatic and manual operation
• Deck pump out fitting and direct overboard pump out for holding tank
• Delta-T engine room ventilation system with supply and discharge fans for proper fresh air supply and water intrusion suppression
• Engine Room entrance package for digital tachometer, engine water temperature, and engine oil pressure, and remote mounted engine start and stop switches for easier viewing and accessibility
• External sea strainers for main engine pick ups
• FBO fuel water separators for main engines
• Fire suppression system, automatically or manually operated and tied into main engine and generator ignition systems with override
• Freshwater supply in engine room for general maintenance and cleaning
• Freshwater manifold isolation system
• Fuel and oil lines, flexible, steel reinforced USCG approved, aircraft type
• Fuel priming pumps, electric 24V DC
• Fuel transfer system, electric 24V DC
• Hour metres on main engines and generator
• Internal sea strainers for generator
• Mufflers – engines, in-line type with surge tubes in engine room
• Mufflers – generators/lift muffler with gas water separator for cleaner, quieter operations
• Oil changing system, gear type pump for main engines, transmissions and generator with pump out line run to cockpit
• PEX plumbing, freshwater system plumbing with manifold system shut off
• Pressurised freshwater system, 110V A/C pump with on deck freshwater fill and cockpit dockside supply inlet with pressure reducing valve
• Propellers, Class “S” pitch tolerance (ISO 484/2) and dynamic balancing. Advanced design cambered blade sections for optimum performance. Nibral alloy for maximum durability.
• Racor fuel/water separator for generator glass bowl type, top loading for easier maintenance – Awlgrip white
• Rudders, stainless steel, composite rudder bearing with dripless seal laminated into hull
• Seacocks, bronze, ball-type sea valves and strainers for all thru-hulls below the water line – Awlgrip white
• Shafts — 2 Aquamet high-strength stainless steel, double-taper with machined keyway and custom thrust plate at main engine couplings
• Steering system, Seastar Optimus electronic steering system
• Struts — thru-water, Nibral
• Trim tabs, dual piston with individual controls w/the trim tab covers on transom
• Twin diesel engines with marine grade reduction gears * See manufacturers information for specifications
• Valve off engine intakes for use as emergency bilge pumps (2)
• Water heater — quick recovery, electric

ELECTRICAL

• 24V DC ship’s service throughout
• 24/12V power supply with breakers on flybridge for future electronics
• 110V outlet in engine room on aft bulkhead
• Anchor light/navigation lights, LED
• Batteries, (2) independent 24V banks mounted in fiberglass storage box
• Battery chargers, (2) with thermal cutoff and switching system for complete integration
• Battery distribution panel with battery cutoff and charging system breakers
• Battery parallel system for main engines and generator start
• Bonded electrical system with ground plate
• Colour-coded, labelled and numbered wiring system with corresponding drawings
• Dimmers, LED interior lighting throughout excluding the companionway
• Emergency DC crossover
• Engine Room lights, LED with DC/AC backup with switch at engine room entrance
• Generator, Diesel — Onan 21.5 kW E-QD (electronic quiet diesel) Series, user-friendly with electronic governing allowing voltage and electronic frequency control
• Glendinning cablemaster (1) with 3 wire grounded cord, (1) additional 50 amp 220V inlet with 50’ cord
• Instrument panel lights for flybridge and main electric panel
• Isolation transformer on cablemasters for more consistent, cleaner voltage
• Lighting, overhead LED lights recessed in ceiling and rope type décor lights concealed by wood valances, 24V throughout
• Master electrical control panel located in salon with 24V/110V circuit breakers, individual switching for shore 1, shore 2, or generator supply and gauges for electrical supply, voltmeter, ammeter and frequency
• Receptacles, 110V duplex with GFCI throughout
• RG6 TV cable to accommodate satellite system
• Sub-panel located in galley with breakers for galley appliances, and galley lights and with gauge for water tank and alarm panel for safety monitoring system
• Voltage stabiliser isolation transformer, on cable reel and inlet for more consistent, cleaner voltage

FLYING BRIDGE

• Black acrylic helm panel for flush mount electronics installation
• Bocatech switching with backlit switch labelling
• Bridge installed without exposed fasteners
• Controls: top mounted single lever electronic controls with station select and keypad
• Electronics lids underside painted satin black
• Electronic trolling valves
• Extended overhang for extra room to move around behind helm and companion seats with anodized aluminium aft railing
• Forward console lounge seat with armrest and storage
• Fire system control with automatic and manual discharge and override system located at console
• Freshwater outlet
• Furuno RD-33 depth finder/sea temperature gauge
• Handrails, powder-coated aluminium effectively positioned above ladder to bridge and at helm
• Helm seat, companion seat, wood, ladder back with 4” pedestals and removable cushions and covers
• Instrumentation based on standard engine package
• Manual engine shutdown switches at radio box
• Non Skid deck moulded for traction and durability
• Offshore Systems monitor with safety monitoring system with audible and visible alarms: fuel levels, fire, engine room temperature, high bilge water, high exhaust temperature, high coolant temperature, low oil pressure and generator as well as confirming correct system operation – includes fuel tank levels
• Port side bench seating with vinyl cushions, storage hatch and aft end lift top storage for bucket
• Recessed radio boxes with split lids, port and starboard console with switch panel inside, painted satin black
• Starboard side bench seating with vinyl cushions, storage hatch and aft end lift top refrigerated drink box
• Stereo 12V w/speakers, flush mounted to aft ends of bridge
• Trim tab control switch mounted at console
• Trumpet style air horns (2), mounted on forward flat section of radar pod
• Under helm access with lights and storage room
• VHF radio ICOM with antenna and mounts

COCKPIT

• Boarding box, fiberglass with nonskid, lift up top and storage
• Cabinet with storage for gaffs and other accessories located port forward gunwale with push release door
• Dockside electric connection — 50 amp/220V electric retractable GlendinningCablemaster (1), located in starboard cabinet under forward gunwale and (1) 50 amp 220V inlet with pushed release door
• Dockside water connection with pressure reducing valve in port side locker under port mezzanine with access thru engine room entrance liner door
• Engine Room access thru mezzanine seat opening with stainless steel piston
• Extended flybridge overhang for shade
• Freshwater wash down with hose bib located in cabinet under forward gunwale
• Gaskets for all lids and access doors
• Grab Rails at cockpit haunch
• Indirect LED rope lighting (white) under coaming
• Ladder to flybridge, one-piece, anodized aluminium with non skid treads
• Laminated backing plate in-deck for future fighting chair or table
• Lazarette hatch with access to steering, trim tabs, drain pumps
• Lighting, recessed tri-color (red, white, blue) LED lights in flybridge overhang
• Live well in transom box without window and light
• Moulded non skid deck
• Observation mezzanine, port aft facing lounge with Sunbrella covered cushions, hinged seat with freezer storage under lounge area, tackle cabinet to starboard with drawers and push release door, and insulated storage box port and starboard
• Recessed in deck fish box starboard live well tub (optional) and dunnage box insulated and removable to port with pump out and drain plate with large holes for easy pump out and cleaning
• Refrigerated drink box undermounted in salon step for direct access from cockpit
• Rod holders, (4) flush mounted
• Rounded cockpit coaming for comfort
• Seawater wash down under starboard gunwale
• Self bailing cockpit with large cockpit scuppers
• Stainless steel cleats and hawse pipes
• Stainless steel gas springs on all hatches and lids
• Stereo speakers tied into flybridge stereo
• Strap with padding to keep transom door and gate open
• Transom fish box, moulded-in
• Transom swim steps at transom door
• Walk-through transom door with lift gate
• Y-valve for fresh and salt water wash downs to port

SALON

• Air conditioning with reverse cycle heat with temperature control that circulates from hidden registers behind valances to maximise comfort while minimising noise and drafts
• Blinds, louvred, mini, for desired natural lighting and additional privacy
• Cabinetry, wood, with drawers and finished maple interior
• Cocktail table, high gloss finish, hi-lo
• Finished wood on galley island and dinette
• Flooring carpeting, wall-to-wall with lined padding for sound absorption and vinyl Amtico flooring at salon entrance – wood trim where Amtico meets carpet
• Headliner, Majilite, natural colour, 1/8” foam and tricot backing
• Home theatre system with 50” flat screen HD TV, Blu-Ray player, soundbar stereo surround sound with powered subwoofer
• Lambrequins, wood frame with fabric upholstery inserts
• Lighting, overhead LED lights recessed in headliner and indirect decorative rope lighting behind valances, 24V DC
• L-shaped lounge with storage underneath on port side of salon
• Main electrical service panel, AC/DC, backlit for easier viewing
• Sliding salon door, moulded fiberglass door with window and wood interior finish, with key lock
• Windows, fixed, frameless side windows with tinting, tempered glass for style, natural lighting, and privacy
• Wood strips in headliner
• Wood valances on port, starboard and aft sides of ceiling

GALLEY/DINETTE

• Bar stools (2) with no backs
• Blinds, silhouette
• Dinette table, high gloss finish with single pedestal, thru-bolted
• Electrical sub panel for galley appliances
• Exhaust fan, high velocity
• Flooring, vinyl Amtico
• Galley countertop, engineered stone with stainless steel sink and satin nickel faucet
• Galley, peninsula style aft galley with raised overhang top inboard and (2) barstools, aft
• Garbage disposal in sink
• Headliner, Majilite, natural colour, 1/8” foam and tricot backing
• Lights, overhead LED lighting
• Microwave/convection oven located in upper galley cabinet above cooktop
• Range, electric surface mounted
• Refrigerator and freezer, Sub-Zero, large capacity, deep-drawer under-counter style with varnished wood faces.
• Storage cabinets in upper galley, varnished wood doors with deep, pullout drawers with slides for smooth movement and latches to keep drawers in place while underway
• Storage cabinets and drawers in lower galley, varnished wood doors and faces with stowage for utensils, and other items; finished maple interiors
• Water tank level gauge

COMPANIONWAY

• Awlgrip bilge areas with access hatches, painted Snow White and lighted for easier maintenance and cleaning
• Central vacuum unit connection with accessories
• Flooring, carpeted steps from galley to companionway
• Headliner, Majilite, natural colour, 1/8” foam and tricot backing
• Laundry centre with stackable, front- loading washer and dryer behind wood door
• Lighting, overhead LED lights recessed in headliner
• Vertical strips in companionway
• Wall panels, natural colour

MASTER STATEROOM (MIDSHIP)

• Air conditioning with reverse cycle heat and temperature control
• Bed, queen-size, walk-around athwartship with upgraded pillow top, Handcraft Viking Slumber #8 with lift up top with gas pistons and maple lined storage underneath
• Bedspread — quilted, designer style with pillow shams (2)
• Drawer storage under bed, (2) large drawers
• End tables on either side of bed with drawer and door storage
• Entry credenza with drawer storage
• Flooring, carpet
• Hanging locker, maple-lined
• Headboard, upholstered
• Headliner, Majilite, natural colour, 1/8” foam and tricot backing
• Lighting, overhead LED lights and decorative indirect rope lighting from underneath bed platform
• Reading lights, overhead with separate switches
• Sheets (1 set)
• TV, 32” HD flat screen with upgraded audio system

GUEST STATEROOM (FORWARD)

• Air conditioning with reverse cycle heat with temperature control
• Bed, queen-size, walk-around with mattress, Handcraft innerspring and lift up top with gas pistons and finished maple interior
• Bedspread — quilted, designer style with (2) pillow shams and (1) set of fitted cotton sheets
• Flooring, carpet
• Hatch, Bomar, foredeck hatch with Ocean Air screen shade system
• Headliner, Majilite, natural color, 1/8” foam and tricot backing
• Lighting, overhead LED lights
• Reading lights with separate switches
• Stereo speakers flush-mounted with headliner
• Storage cabinets, port of bed, wood
• Storage drawers under bed, (2) large drawers
• Wood shelf

GUEST STATEROOM (STARBOARD)

• Air conditioning with reverse cycle heat with temperature control
• Bed, queen with Handcraft mattress innerspring and lift up top with gas pistons and maple lined storage underneath
• Bedspread — quilted, designer style with pillow shams (2) and sheets (1) set
• Flooring, carpet
• Hanging locker, maple-lined
• Headliner, Majilite, natural colour, 1/8” foam and tricot backing
• Lighting, overhead LED lights
• Stereo speakers flush-mounted with headliner

MASTER AND GUEST HEAD

• Air conditioning/heat with vent in soffit
• Countertops, engineered stone
• Electric heads plumbed with Y-valve for overhead discharge or direct to holding tank
• Exhaust fan with vent in shower
• Flooring, Amtico
• Linen storage
• Lights, overhead LED lights recessed in soffit and in ceiling
• Lower vanity with wood door
• Receptacle, 110V – GFCI
• Shower light
• Stall shower, fiberglass with satin nickel shower fixtures and drain to automatic sump pump in bilge
• Towel bars and rings — satin nickel
• Upper vanity, medicine cabinet with mirrored doors

MISCELLANEOUS

• Anchor — constructed with a high-tensile, corrosion resistant aluminium magnesium alloy
• Anchor locker with access from foredeck
• Anchor rode, 250’ with 50’ of chain
• Awlgrip lazarette, engine, anchor locker and forward bilges
• Bonding system anode on transom
• Bow pulpit, moulded fiberglass with non skid and stainless steel anchor chute
• Bow rail, anodized aluminium, brushed finish
• CO2 detectors throughout
• Fire extinguishers (5)
• Fuel, standard capacity
• Magnetic switches for lights in all forward bilge compartments
• Mooring lines, braided nylon (6)
• Painted rub rail
• Positive catches on all stateroom doors to secure open
• Recessed trim tab covers
• Ships bell
• Side mounted, wrap around grab rails, powder-coated aluminium that follows the window line
• Smoke detector
• Stainless steel bow, spring and stern cleats thru-bolted to aluminium backing plates
• USB receptacle (Apple compatible) in staterooms and salon
• Viking one year limited warranty (available upon request)
• Viking Prestige Decor package
• Water delivery kit with tool set (N)

STANDARD POWER: MAN V12 1400CRM:1400MHP
INTERIOR

• Satin interior finish throughout (J)
  *Standard will be high gloss horizontal grain walnut. See Viking sales professional for details

COCKPIT

• Live well in cockpit sole
• Outriggers, Rupp w/spreaders,grommets and halyards (K)
• Swim platform & ladder
• Transom lettering
• Window and light in transom box live well

DECK/EXTERIOR

• Additional (2) foredeck hatches w/ sunshade
• Bow pulpit removal
• Bow thruster DC
• Custom hull colour, gelcoat (J)
• Davit, (1100lb), w/hydraulic lift & rotation
• Fender racks
• Salon forward window mask
• Windlass, Lewmar V4 SS w/ 50’ chain, 250’ rope

DECOR (S)

• Custom decor (H)
• Classic decor, accessory kit
• Essential galley, accessory kit

FLYING BRIDGE

• Air conditioning (K)
• Center rigger (K)
• Electronic single lever controls for pod
• Fiberglass helm pod and stainless steel steering wheel
• Hardtop w/molded-in LED lights (V)
• Lights, remote spotlight (K)
• Radar mast single (K)
• Release wood helm pod
• (6) Rod rocket launcher (K)
• Three sided enclosure to back of helm w/center panel “U” zip (K)
• Three sided Costa Clear enclosure to back of helm

SALON

• Carpet runner – full
• Carpet runner – partial
• Carpet runner – companionway and steps

MASTER STATEROOM

• Electronic safe under bed

GUEST STATEROOM – FWD

• Crossover stateroom arrangement
• Island queen bunk
• TV, flat screen

GUEST STATEROOM – PORT

• TV, flat screen

DELIVERY

• Propellers, spare and removal/installation tool

ENGINEROOM

• ElectroSea for air conditioning/refrigeration
• Eskimo ice machine
• Generator, additional 13.5 kW
• Optional fuel tank
• Seakeeper 9
• Seakeeper 18
• Spot Zero/watermaker combo unit
• Water maker, 700 GPD w/auto backflush

OPTIONAL POWER:

• MAN V12 1550CRM: 1550MHP
