VALHALLA V-33

CONSTRUCTION

• Awlgrip underside of deck coaming for improved finish
• Blister resistant modified vinylester resin in entire boat
• Forward anchor locker with built in anchor tube and shelf, painted Awlgrip finish
• Fresh water tank, polyethylene
• Fuel tanks (3) 3/16” 5052 H32 aluminum coal tar epoxy finish
• High performance isophthalic gelcoat NPG superior gloss flexibility and outstanding weathering characteristics
• Holding tank, polyethylene
• Hull molded fiberglass construction, using closed cell foam core in selected areas for optimized strength and stiffness while minimizing weight
• Hull gelcoat Snow White
• Integrated Seakeeper mounting structure, molded in stringer grid
• Lower guard rail to match hull color, painted with stainless steel insert
• Molded fiberglass aft lazarette liner
• Molded fiberglass cockpit liner with integrated gutter system
• Nonskid for traction and durability
• Patented Michael Peters Stepped V Ventilated Tunnel running surface designed to reduce drag while increasing speed, stability and efficiency
• Rub rail, painted white with stainless steel insert
• Stainless steel through hulls — Titanium below waterline
• Stringers, infused fiberglass with integrated wire chases
• 316 stainless steel hardware throughout

CONSOLE/SEATING MODULE

• Black acrylic helm panel for flush mount electronics installation
• Compass, flush mounted at helm, lighted
• Costa Marine armrests for forward lounge seating
• Electrical panel door for easy access to backside of helm and electronics equipment
• Electric freshwater head with Y valve plumbed to holding tank
• Fiberglass entry door to console interior with notched overhead for easy entry. Heavy duty stainless locking door hardware
• Fiberglass helm pod
• Forward lounge seating integrated into console with dry storage with (2) Gemlux cup/rod holders
• Flush mounted cup holders on helm (4)
• Fiberglass seating module with slide out cooler and cushion
• Glove box to port with USB charging outlets and 12V plug
• Molded in vanity with freshwater sink and retractable shower wand
• Powder coated pedestal with composite ladder treads for easy access into console
• Edson stainless steering wheel with power knob
• Recessed fiberglass footrest with storage
• Upholstered bench seat with tackle storage and (6) Gemlux rod holders with (5) cup holders installed on bench seat backrest

COCKPIT

• Aft fishboxes port, starboard and center storage box plumbed to Y-valve with Whale Gulper. Forward fishbox and port/starboard deck boxes plumbed to automatic sump box with Whale Gulper pump located in the mechanical compartment inside console
• Bow rail, polished aluminum, recessed and low profile
• Durable white outdoor upholstery for console lounge, bench seating, coaming bolsters and cockpit cooler seating
• Freshwater wash down with hose bib located under gunwale and anchor locker
• Heavy duty gasketing for all hatches with installation detail molded in for tight seal
• Pressurized transom live well with fiberglass lid
• Port side dive door
• Rod holders, cockpit coaming, (6) stainless Gemlux
• Salt water washdown
• Self-bailing cockpit with large cockpit scuppers
• Stainless 8” pop-up spring and forward cleats. Stainless hawse pipe and fixed cleat aft in cockpit.
• Stainless steel gas pistons on deck hatches
• Side storage lockers port and starboard

MECHANICAL

• Aft bilge pumps (2), connected to float switches for automatic operation and manual operation through on-dash Bocatech switches
• Auto sump box located in console mechanical space
• D/C pressurized freshwater system with freshwater fill on console
• Deck pump-out fitting for holding tank
• Electric horns, Schmitt/Ongaro bulkhead style, mounted forward under coaming
• Electronic power assist steering
• Fuel manifold system
• High water alarm
• Hooker sea chest live well system with high speed pickup and single 2500 variable speed pump with control knob at helm
• Mid-bilge pump with float switches for automatic operation and manual operation through on-dash Bocatech switches
• PEX, freshwater system plumbing
• Zip-wake trim control system

ELECTRICAL

• 60 AMP battery charger (1) with separate 30 amp shore cord, 50’
• Anchor light/navigation lights
• Batteries, Odyssey Group 31. One (1) per engine and (2) additional house batteries
• Battery distribution panel with battery cutoff and charging system breakers
• Battery voltage display
• Bocatech 12V switching with backlit switch labeling
• Color-coded, labeled and numbered wiring system
• LED interior console lighting and under gunwale multi-color lighting
• 1kW transducer pocket

DELIVERY

• Supply loose on board, (1) R & R Designs 2-step emergency boarding ladder

ENGINE OPTIONS

• Twin Mercury V8 450R cold fusion white w/EPS Seastar Optimus steering
• Twin Mercury Verado 400 cold fusion white w/EPS Seastar Optimus steering
• Twin Mercury Verado V8 300 cold fusion white w/EPS Seastar Optimus steering
• Twin Yamaha F300 white
• Twin Yamaha F300 white w/Seastar Optimus joystick system

CUSTOM TOP OPTIONS

• Fiberglass hardtop w/polished aluminum supports aft/fwd facing molded-in Lumitec mirage spreader lights, (6) rod rocket launcher, molded-in overhead electronics pod, molded-in radar pod & overhead lights (4) (white/black)
• Custom fabricated fold-down Marlin tower w/removable sunshade (PBT to install)
• Outrigger bases, Gemlux
• Outrigger poles Rupp 18’ (fixed)
• Outrigger poles, Gemlux, carbon fiber, 18’ (telescoping)
• Outrigger poles, Gemlux, internally rigged, 18’ (fixed)
• Underside hardtop to match hull color
• Molded-in speaker pods
• Powder coating package (white/black/grey)
• Lumitec Razor light bars (2) mounted fwd hardtop
• Electric teaser reel box with mounting bracket, recessed opening and removable door in hardtop
• Miya Epoch US-6, 12V electric teaser reels
• Pancake style teaser reels, w/molded-in recess into hardtop

FISHING ACCESSORIES

• Additional live well pump, Hooker electric 2,500 w/ variable speed controller at helm (each) Upgrade standard Hooker electric 2500 pump to 4500 pump
• Additional upgraded live well pump, Hooker electric 4500 w/variable speed controller at helm
• Additional in-deck live well (N/A with Seakeeper)
• On deck live well inlet and discharge fittings located in transom corners (each)
• Electric reel outlet, 12V (each)
• Rod holders, swivel Gemlux (each)
• Rod holders, additional Gemlux (each) (specify console, lounge, coaming)
• Cup/rod holders Gemlux (each)
• Rod storage, mounted under gunwale
• Clear transom live well lid
• Light only, for transom live well
• Light only, for lounge live well
• Window and light in transom live well
• Valhalla filet table
• Release Marine Rocket Launcher

GELCOAT AND PAINT

• Boot stripe, paint
• Bottom paint
• Hull colour, gelcoat, light colour (KG, SB, BB)
• Hull colour, gelcoat, two-tone at Chine, light colour
• Hull colour, gelcoat, dark colour (HG, NG, FB, SS, SG)
• Hull colour, gelcoat, two-tone, dark colour at Chine
• Hull cocolourlor, paint
• Lounge live well colour Aristo Blue
• Transom Live well colour Aristo Blue (each)
• Topside gelcoat, all topsides including console, liner and deck boxes (specify light colour)
• Custom outboard paint package

CONSOLE

• Costa Clear single panel for helm
• ProCurve solid curved glass enclosure for helm
• Edson steering wheel with power knob, carbon fiber
• Edson steering wheel with power knob, black finish
• Edson steering wheel, teak

SEATING

• Full beam aft removable bench seat
• Integrated GG Schmitt transom seats
• Release Marine armrests for standard bench seat
• Release Marine teak helm chairs, (2), 19” w/4 armrests, electric slides and flip-up bolsters
• Forward bench seating module with backrests, (2) and cupholders, (2)
• Removable fiberglass insert to make U-shaped forward seating
• Upgraded Release Marine jump seat backrests (2)

UPHOLSTERY

• Costa Marine cover package to include console, lounge, helm seating (white/grey/roast/black)
• Costa Marine, full boat cover (white/grey/roast/black)
• Costa Marine, engine covers (white/grey/roast/black)
• Costa Marine sunshade Aft w/carbon fiber poles
• Costa Marine sunshade, Fwd w/carbon fiber poles
• Costa Marine sunshade, Fwd w/stainless poles
• Costa Marine wing panels, half
• Costa Marine, wing panels full
• Diamond/Bentley stitching
• Diamond/Bentley stitching, double
• Upgraded upholstery for seating and coaming with optional colours

ENHANCEMENTS AND CONVENIENCE

• Anchor chute w/SS plow anchor plus windlass
• Additional pop-up cleats aft in lieu of standard fixed cleat and hawse pipe
• Additional cup holders (each)
• Arid dry bilge system (2 zone)
• Bow table, hi-low
• Bow thruster
• Bow towing eye
• Engine flush system, Reverso automatic
• Extra battery, additional Odyssey Group 31 (each)
• Fiberglass under gunwale forward side locker
• Seakeeper, SK 2
• Release Marine teak helm pod
• Faux teak helm pod
• Faux teak toe rail
• Faux teak transom
• Deck box LED lighting to include all deck and coaming boxes
• Macerator pump, holding tank overboard discharge
• Recessed speaker rings
• Refrigerate fish boxes (each)
• Removable stainless dive ladder
• Underwater lights (4)
• Trailer, aluminum
• Transom name done by outside vendor
• USB charging outlets and 12V power outlet inside console
• Valhalla filet table
• Water delivery w/out anchor
• Water delivery kit
  *USCG Compliance items including fire extinguishers, flare kit, life jackets with stowage bag, and ring buoy. Fortress anchor with a custom rode, stainless steel chain, 200’ rope, and (1) 25’ coiled washdown hose. Also includes Shurhold boat maintenance kit, first aid kit, 5 gallon bucket, fenders with lines, and 6 dock lines

ELECTRONIC PACKAGES

• Garmin package, factory installed
• Simrad package factory installed
• Upgraded 2 kW transducer for factory installed (Garmin/Simrad package)
• Install dam for 2kW transducer
• Entertainment package
• Entertainment package, custom
• Navigation package, custom

Enter the Upper Echelon. The V-33 is an ideal choice for owners looking to get into their first Viking-built boat and experience all of its inherent benefits. The same robust standard equipment list and nearly all of the options for the V-37 and V-41 are available on this twin-outboard, high-performance center console.

The patented Stepped-V Ventilated Tunnel delivers the softest, driest and most efficient ride of any center console in this size range. The V-33 possesses big-boat technology. High-tech features include joystick helm control with GPS station-keeping, a bow thruster and gyroscope stabilization and more.
